    12mm Od X 1.5 Mm 10mm OD X 2m Stainless Steel Sanitary Pipe 1.5 Inch A270 152mm

    Ask Lasest Price
    Brand Name : Rex Metal
    Price : USD/RMB/EUR
    Payment Terms : L/C, T/T, EXW, D/A, D/P, Western Union, MoneyGram
    Delivery Time : 5-20days
    Certification : ISO,BV
    • Product Details
    • Company Profile

    12mm Od X 1.5 Mm 10mm OD X 2m Stainless Steel Sanitary Pipe 1.5 Inch A270 152mm

    A270 Stainless Steel Sanitary Pipe Tubing 152mm Stainless Sanitary Tubing

    Product Description

    Instrumentation Tubing is a vital part of Tubing system which widely used with Instrumentation Tube Fittings. Proper Tubing selection with Tubing standard,tolerance,wallthickness,material,temperature,surface finish into consideration are necessary.



    Typicall material :


    Seamless and redrawn
    ASTM GradeUNS no.ConditionSpecifications
    304S30400HardAMS 5566/5564
    304S30400HardMILT 5695
    304S30400HardLN 9396
    304S30400HardLN 9398
    304S30400AnnealedMILT 8504
    304LS30403HardAMS 5569
    304LS30403Hard or annealedAIR 9164
    304LS30403Hard or annealedAIR 9160
    304LS30403AnnealedAIR 9424
    321S32100AnnealedAMS 5645, AMS 5557/5570
    321S32100Hard or annealedAIR 9164
    321S32100Hard or annealedAIR 9160
    321S32100AnnealedAIR 9423
    321S32100AnnealedAIR 9424
    321S32100AnnealedBSI T67
    321S32100AnnealedLN 9396
    321/347S34700AnnealedLN 9398
    347S34700AnnealedAMS 5571/5556
    347S34700HardBSI T68
    347S34700AnnealedBSI T66
    347S34700AnnealedBSI T72
    347S34700AnnealedMILT 8808
    304/304LS30400/S30403HardMILT 6845
    304L/321/347S30403/S32100/S34700AnnealedMILT 8606
    304L/316L/321/347S30403/S32100/S34700HardMILT 8973
    Alloy 625N06625AnnealedAMS 5581
    Alloy 718N07718AnnealedAMS 5590
    Nickel 200N02200Annealed

    Typical dimensions for aerospace applications range from 0.25 mm (0.010 in.) to

    50.80 mm (2.0 in.) outside diameter.


    other Stainless steel Tubing Dimension ranges :


    Product NameExecutive StandardDimensionSteel Code / Steel Grade
    Industrial PipesASTM A312, A358, A778, JIS G3459OD: 1/4"~40"TP304, TP304L, TP316L, SUS304TP
    WT: SCH5S~SCH80S
    Tubes for Boiler and Heat-Exchanger, General Service TubingASTM A249, A269, JIS G3463OD: 15.9~139.8mmTP304, TP304L, TP316L, SUS304TB
    WT: 1.6~5.0mm
    Mechanical and Structural TubesASTM A554, JIS G3446OD: 7.9~152.4mmMT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD SUS304
    WT: 0.5~6.5mm
    Square TubesASTM A554OD: 12.7x12.7~150x150mmMT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
    WT: 0.7~6.5mm
    Rectangular TubesASTM A554OD: 10x20~100x200mmMT304, MT304L, MT316L, MT430 Grade 201, 202 as per mill's STD
    WT: 0.7~6.5mm
    Large Gauge Pipes for Ordinary PipingJIS G3448OD: 15.88~318.5mmSUS304TPD
    WT: 0.8~3.0mm
    Large Diameter PipesJIS G3468OD: 14"~40"SUS304TPY
    WT: SCH5S~SCH40S

    Aplication


    304 stainless steel pipe tubing


    Packing and Shipping


    304 | 304L | 304H Stainless Steel Seamless Pipes 0


    304 | 304L | 304H Stainless Steel Seamless Pipes 1


    Company Profile

    Jiangsu Rex Metal Products Co., Ltd was established in 2010, located in Jiangsu Province,and has our factories of with 2000㎡. Our main products include steel plates,steel pipes, steel bars(rods) etc, which have been exported to over 30 countries like England, Australia, South Korea, Russia, Brazil, Turkey, India, Indonesia, South Africa, Ecuador, Uzbekistan, Thailand etc.

    We have advanced production facilities, producing center with cutting machines, punching machines, water jet cutting machines, polishing machines, plate shearers and draw benches etc. We have passed theIS09001 quality system,and EU CE system. Our aim is to provides with good quality steel products and better service. We support SGS, BV and other third party test.

    We will always welcome all the customers and friends all over the world to visit our factories and reach great cooperations.


    FAQ

    Q1: Are you trading company or manufacturer ?
    A: We are a professional manufacturer with 20 years' experience and have took part in international trade for 10 years.

    Q2: How about your quality and how do you guarantee the quality?
    A: All products we supply is primary as you need, Our company is certificated to ISO9001: 2008, and every product will be tested for 4-5 processes. We welcome customers or the third party inspection agencies to come to our factory for inspection.

    Q3: Do you provide samples ? Is it free or extra ?
    A: Yes, we could offer the sample for free charge.

    Q4: How long is your delivery time?
    A: For Stocks, we can send the goods to loading port within 7 days after receiving the deposit ;
    For production period, it usually needs about 15 days ~30 days after receiving the deposit.

    Q5: What is your terms of payment ?
    A: Usually 30% deposit by TT in advance and balance against copy pf BL or L/C at sight.
